High Speed Grinding Machine for Gate Valve

High Speed Grinding Machine for Gate Valve
Model Name : MZ600
Valve type: Gate Valve
Seat Type : Flat Type
Power: 1100KW
Made in China

EMAIL

Portable Gate Valve Grinding Machine CMX-MZ600


       The Caminix portable valve grinding machines are a patented design grinder that is a proven solution for on-site industrial valve reconditioning and maintenance.Repairing leaking valves in industrial pipelines is a laborious operation that involves extended downtime, production losses and substantial unwanted costs. Losses are minimized if the valves can be reground in situ, precluding the need to dismantle and remove defective valves from the pipeline. Available in overlapping sizes, these grinders combine unsurpassed versatility with exceptional ease of handling and operation. A combination guaranteed to give these grinders cutting edge performance, whatever the valve location.


        These valve grinding machines have unique, lightweight which allows rapid and accurate mounting for grinding valve seats or wedges. Operating checks and replacement of abrasive discs can be carried out without disturbing the assembly.

you can quickly change grinding disks and adjust the grind pressure,Solid construction, sealed lubrication and pre-loaded bearings ensure long life and low maintenance.




Specifications of  Gate Valve Girnding & lapping Machines


CMX-MZ600 GATE VALVE

  GRINDING & LAPPING

Specifications

INCH

METER

Seat  Diameter

Range

Φ8’’-Φ 24’’

Φ220-Φ630

Submerging Depth

36 inch

900mm

Valve Type

Gate Valve

Power Option

Electric  or  Pneumatic

Power

1100KW

Approx Weight

60 KG



For more information, please contact sales@caminix.com.
